Which device is the SSR Add-on compatible with?

It is an accessory for The Pill by Shelly. It connects through the intermediate 5-Terminal Add-on adapter, sold separately; it does not mate directly with The Pill.

What loads can the two outputs switch?

Each channel (LOAD1 and LOAD2) switches a direct-current load of up to 30 V and 300 mA, for example LED strips, small fans, solenoids or micro-motors.

Can I switch 230 V AC mains with this module?

No. The outputs are only for low-voltage direct current up to 30 V DC. For 230 V AC you must use a mains-rated relay, not this accessory.

What are the module's dimensions and weight?

The black housing measures 36 x 31 x 11.5 mm and weighs 12 g, making it easy to place inside junction boxes or compact enclosures.

Does the relay make noise when switching?

No. As a solid-state relay, switching is electronic with no moving contacts, so it is silent and of mechanical wear over time.

Is the product in stock at CasaSmart?

The card is currently in draft status and the product is listed as out of stock. The CasaSmart team in Chisinau can inform you about availability and the required components.

Shelly SSR Add-on for The Pill

Name: Shelly SSR Add-on for The Pill, dual-channel solid-state relay output
Brand: Shelly
SKU: SHELLY-PILL-SSR-ADD-ON

casasmart.md

What it is, who it's for, what it does

About this product

The Shelly SSR Add-on is a compact accessory module for The Pill by Shelly that adds two solid-state relay outputs (LOAD1 and LOAD2) for switching direct-current loads of up to 30 V and 300 mA per channel.<br><br>Both outputs are galvanically isolated and act as potential- contacts, switching silently and without mechanical wear, which suits them for LED strips, small fans, solenoids and other low-voltage DC consumers. The module also provides one configurable digital input/output, IO3, at a 3.3 V logic level.<br><br>The black housing measures only 36 x 31 x 11.5 mm and weighs 12 g, while its own power draw stays below 0.6 W. Connecting to The Pill requires the separate 5-Terminal Add-on adapter. This card is in draft status and is currently out of stock at CasaSmart in Chisinau.

Delivery
Free from 1500 MDL
Returns
30 days to return
Warranty
24 months

15+projects delivered300+devices installed3 yearslocal-first experienceChișinăushowroom Columna 153Book a showroom visit →

Where it works

Use cases

Decorative under-cabinet lighting in a Chisinau apartment, controlled through The Pill.

Turning a 12 or 24 V LED strip on and off from an SSR output, without the click of a mechanical relay.

An irrigation setup for a garden or terrace, built into Shelly scenes.

Switching a DC solenoid valve on the LOAD1 channel to start automatic watering.

Ventilation of a technical cabinet in an office, triggered by temperature read by The Pill.

Energising a 5-30 V fan for cooling or ventilation when a sensor crosses a threshold.

Analytics

See consumption — save on bills

Real-time consumption tracking via the eWeLink app. Daily, weekly and monthly history helps identify the most energy-hungry devices.

For the installer

Technical specifications

full spec · wiring · datasheet

Physical

Outputs: 2 solid-state relay channels (LOAD1, LOAD2), potential-
Dimensions: 36 x 31 x 11.5 mm
Weight: 12 g

Power

Max output voltage: 30 V DC
Max output current per channel: 300 mA
Isolation: galvanically isolated outputs
Power consumption: < 0.6 W

Connectivity

Digital I/O: 1 configurable IO3 at 3.3V logic
Compatibility: The Pill by Shelly via 5-Terminal Add-on (sold separately)

Environment

Operating temperature: 0 to 40 °C
Humidity: 30 to 70 % RH

Full device datasheet

Support

Frequently asked questions

Which device is the SSR Add-on compatible with?
It is an accessory for The Pill by Shelly. It connects through the intermediate 5-Terminal Add-on adapter, sold separately; it does not mate directly with The Pill.
What loads can the two outputs switch?
Each channel (LOAD1 and LOAD2) switches a direct-current load of up to 30 V and 300 mA, for example LED strips, small fans, solenoids or micro-motors.
Can I switch 230 V AC mains with this module?
No. The outputs are only for low-voltage direct current up to 30 V DC. For 230 V AC you must use a mains-rated relay, not this accessory.
What are the module's dimensions and weight?
The black housing measures 36 x 31 x 11.5 mm and weighs 12 g, making it easy to place inside junction boxes or compact enclosures.
Does the relay make noise when switching?
No. As a solid-state relay, switching is electronic with no moving contacts, so it is silent and of mechanical wear over time.
Is the product in stock at CasaSmart?
The card is currently in draft status and the product is listed as out of stock. The CasaSmart team in Chisinau can inform you about availability and the required components.
