Moes · ZB-TDD12-RCW-4-MS

Moes ZB-TDD12-RCW-4-MS recessed Zigbee RGBCW downlight 12W, 1400 lm

Name: Moes ZB-TDD12-RCW-4-MS recessed Zigbee RGBCW downlight 12W, 1400 lm
Brand: Moes
SKU: ZB-TDD12-RCW-4-MS
Price: 459 MDL
Availability: InStock

459 MDL3 left

Recessed downlights

Zigbee

Manufacturer images

459 MDL3 left

What it needs to work

A compatible hub is required.

Suitable gateways and hubs

Buy with installation

Check compatibility

Cut-out diameter: 109–140 mm
Luminous flux: 1400 lm
Beam angle: 120°

A 12W Zigbee recessed downlight, 1400 lm, 120° beam: 2700–6500K white plus RGB, 1–100% dimming. 109–140mm cut-out per the maker, Ø140mm face, 64mm high. Needs a Zigbee gateway (sold separately).

17 specifications from manufacturer documents

We deliver across Moldova. Availability, delivery timing and cost are confirmed with a manager before order fulfilment.

The right choice starts with specifications

Device passport

SKU: ZB-TDD12-RCW-4-MS

Specifications checked against the linked manufacturer documents.Checked 18 October 2026

Housing and installation4

Cut-out diameter — what it means The diameter of the ceiling hole the light fits into. A range means the spring clips hold the light in holes of different sizes — handy when replacing old spots. For rectangular lights, see the rectangular cut-out size.	109–140 mmThe manufacturer gives a 109–140 mm hole, but the front diameter is also 140 mm, so a hole near the upper limit would not be covered by the trim; check against the light before cutting [1]
Recess depth — what it means How much free space above the ceiling the light needs. Matters for stretch and suspended ceilings with a small gap and where beams or pipes run above the ceiling.	64 mmOverall height of the light from the manufacturer's drawing; the part above the ceiling is smaller by the thickness of the front trim [1]
Ingress protection (IP) — what it means Protection against dust (first digit) and water (second). IP20 is for dry rooms only, IP44 resists splashes, IP65 and up handle water jets and outdoor use.	Not stated by the manufacturer
Dimensions — what it means The device’s size in millimetres as the maker states it. Check that it fits the wall box, niche or shelf.	Ø140 × 64 mmFront diameter × height. The drawing also shows the body at 109 mm by the spring clips and 80 mm at the rear [2]

Lighting7

Luminous flux — what it means How much light the fixture or bulb gives at full brightness, in lumens. As a guide, about 800 lm is roughly what a 60 W incandescent bulb gave. A room is usually lit by several sources, and their flux adds up.	1400 lm [2]
Beam angle — what it means How widely the light spreads. A narrow beam (up to 25°) picks out a single object with a spot; 30–40° gives directed light on a table or wall; 60° and wider gives even light on the floor and general lighting. For the same luminous flux a narrow beam gives a smaller but brighter spot.	120° [2]
Light colour — what it means What light the fixture can give: one shade of white, tunable white from warm to cool, or colour as well. Tunable white lets you, for example, make the light warm in the evening and neutral during the day.	RGB + tunable white16 million RGB colours and white 2700–6500 K [2]
Colour temperature — what it means The range of white shades in kelvin: 2700 K is warm like an incandescent bulb, 4000 K neutral, 5700 K and above cool, close to daylight. If the shade is fixed, both values are the same.	2700–6500 K [2]
Colour rendering index (CRI, Ra) — what it means How natural colours look under this light, on a scale up to 100 (Ra). At Ra 80 colours look slightly duller; at Ra 90 and above skin, food, wood and fabrics look closer to how they do in daylight.	Not stated by the manufacturer
Minimum dimming level — what it means How far the light can be dimmed, as a share of full brightness. The smaller the number, the dimmer it can go at night or during a slow fade: for example, 1% and 0.1% look clearly different in a dark room.	1%Brightness is set in the MOES / Tuya app from 1 to 100 % [2]
Glare rating (UGR) — what it means How much the light dazzles when you glance at it from the side. The lower the number, the less discomfort: UGR below 19 is the norm for workspaces, below 16 for calm lighting. Many makers do not publish it.	Not stated by the manufacturer

Power4

Rated power — what it means The rated or maximum power draw from the spec sheet. It sets the load on the socket and the energy use.	12 WTolerance ±5 % [2]
Driver (power supply) — what it means Where the LED power supply sits. Built into the housing means the fixture connects straight to the 230 V wires; a separate box on a cable needs room above the ceiling or next to the fixture.	Not stated by the manufacturer
Standby power — what it means How much power the device draws on its own while idle. It matters for devices that run around the clock.	Not stated by the manufacturer
Supply voltage — what it means The supply voltage (and current, if stated) as the maker gives it. It must match your mains or adapter.	110–240 V ACMains frequency is not stated [2]

Connectivity and compatibility7

Connectivity — what it means The wireless link or network the device uses. Wi-Fi connects straight to the router; Zigbee, Thread and Bluetooth Mesh work through a hub or gateway.	ZigbeeThe Zigbee version is not stated [2]
Hub required — what it means Whether the device needs a separate hub, gateway or coordinator to work in a smart home. If so, it is sold separately unless stated otherwise.	RequiredPage: a Zigbee gateway is required for operation and is sold separately [2]
Matter support — what it means Whether the device supports the Matter standard, directly or through a bridge. Matter lets you add it to Apple Home, Google Home, Alexa and Home Assistant.	Not stated by the manufacturer
Home Assistant — what it means How the device connects to Home Assistant: a built-in integration, a Zigbee coordinator, Matter or the maker’s cloud integration.	Not stated by the manufacturer
Radio frequencies and transmit power	2.402–2.480 GHz [2]
Transmit power — what it means The coordinator's maximum radio output. Higher power gives a steadier link to distant devices, but range in a home depends more on walls and the number of routers in the network.	16 dBmMaximum transmit power is below +16 dBm [2]
App — what it means The maker’s app used to set up and control the device.	MOES, Tuya Smart / Smart Life [2]

Model and version1

Colour — what it means The housing colour of this model. Other colours in the same series are separate products.	WhiteWhite housing and trim in the official photos and drawing [1]

Package contents1

Manufacturer warranty — what it means The warranty period the maker states. Confirm warranty terms in Moldova with the seller.	24 monthsPer the MOES warranty terms in the manual attached to the page, from the date of purchase. The manual is issued for the 9 W version (ZL6095TD) [3]
