Moes · ZB-LZD10-RCW

Moes ZB-LZD10-RCW recessed Zigbee RGBCW downlight 2700–6500K, 10W, Ø132mm

Name: Moes ZB-LZD10-RCW recessed Zigbee RGBCW downlight 2700–6500K, 10W, Ø132mm
Brand: Moes
SKU: ZB-LZD10-RCW-MS
Price: 549 MDL
Availability: InStock

549 MDLIn stock

Recessed downlights

Zigbee

Manufacturer images

549 MDLIn stock

What it needs to work

Page FAQ: a hub is required and the maker recommends a Tuya Zigbee hub. The manual requires a Zigbee hub in the app before the light is added. The hub is sold separately.

Suitable gateways and hubs

Buy with installation

Check compatibility

Luminous flux: 900 lm

A 10W Zigbee recessed downlight: Ø132mm face, 58mm high, 2700–6500K white plus RGB, 100–240V. Needs a Zigbee gateway (sold separately); control from MOES / Smart Life, Alexa and Google Home.

17 specifications from manufacturer documents

We deliver across Moldova. Availability, delivery timing and cost are confirmed with a manager before order fulfilment.

The right choice starts with specifications

Device passport

SKU: ZB-LZD10-RCW-MS · Document model: ZB-LZD10-RCW

Specifications checked against the linked manufacturer documents.Checked 18 October 2026

Housing and installation4

Cut-out diameter — what it means The diameter of the ceiling hole the light fits into. A range means the spring clips hold the light in holes of different sizes — handy when replacing old spots. For rectangular lights, see the rectangular cut-out size.	Not stated by the manufacturer
Recess depth — what it means How much free space above the ceiling the light needs. Matters for stretch and suspended ceilings with a small gap and where beams or pipes run above the ceiling.	58 mmOverall height of the light from the manufacturer's drawing; the part above the ceiling is smaller by the thickness of the front trim. The drawing is shared by the page's 7 W and 10 W versions and does not name the version [1]
Ingress protection (IP) — what it means Protection against dust (first digit) and water (second). IP20 is for dry rooms only, IP44 resists splashes, IP65 and up handle water jets and outdoor use.	Not stated by the manufacturer
Dimensions — what it means The device’s size in millimetres as the maker states it. Check that it fits the wall box, niche or shelf.	Ø132 × 58 mmFront diameter × overall height; body diameter behind the trim 60 mm. The drawing is shared by the 7 W and 10 W versions [1]

Lighting7

Luminous flux — what it means How much light the fixture or bulb gives at full brightness, in lumens. As a guide, about 800 lm is roughly what a 60 W incandescent bulb gave. A room is usually lit by several sources, and their flux adds up.	900 lmThe ZB-LZD7-RCW manual gives a single 900 lm figure for the "7W/10W" series without saying which version it applies to [2]
Beam angle — what it means How widely the light spreads. A narrow beam (up to 25°) picks out a single object with a spot; 30–40° gives directed light on a table or wall; 60° and wider gives even light on the floor and general lighting. For the same luminous flux a narrow beam gives a smaller but brighter spot.	Not stated by the manufacturer
Light colour — what it means What light the fixture can give: one shade of white, tunable white from warm to cool, or colour as well. Tunable white lets you, for example, make the light warm in the evening and neutral during the day.	RGB + tunable whiteManual: RGB + cool + warm white; page: 16 million colours and white 2700–6500 K [2]
Colour temperature — what it means The range of white shades in kelvin: 2700 K is warm like an incandescent bulb, 4000 K neutral, 5700 K and above cool, close to daylight. If the shade is fixed, both values are the same.	2700–6500 KThe range is given in the product title and description on the official page; the manual says only "RGB+Cool+Warm" [3]
Colour rendering index (CRI, Ra) — what it means How natural colours look under this light, on a scale up to 100 (Ra). At Ra 80 colours look slightly duller; at Ra 90 and above skin, food, wood and fabrics look closer to how they do in daylight.	Not stated by the manufacturer
Minimum dimming level — what it means How far the light can be dimmed, as a share of full brightness. The smaller the number, the dimmer it can go at night or during a slow fade: for example, 1% and 0.1% look clearly different in a dark room.	Not stated by the manufacturer
Glare rating (UGR) — what it means How much the light dazzles when you glance at it from the side. The lower the number, the less discomfort: UGR below 19 is the norm for workspaces, below 16 for calm lighting. Many makers do not publish it.	Not stated by the manufacturer

Power4

Rated power — what it means The rated or maximum power draw from the spec sheet. It sets the load on the socket and the energy use.	10 WThe manual lists power as "7W/10W" for the two versions [2]
Driver (power supply) — what it means Where the LED power supply sits. Built into the housing means the fixture connects straight to the 230 V wires; a separate box on a cable needs room above the ceiling or next to the fixture.	Built into the housingOfficial photos show the mains leads coming straight out of the housing; no separate driver box is shown or listed [4]
Standby power — what it means How much power the device draws on its own while idle. It matters for devices that run around the clock.	Not stated by the manufacturer
Supply voltage — what it means The supply voltage (and current, if stated) as the maker gives it. It must match your mains or adapter.	100–240 V AC, 50/60 HzThe MOES store page states AC 110–250 V [2]

Connectivity and compatibility6

Connectivity — what it means The wireless link or network the device uses. Wi-Fi connects straight to the router; Zigbee, Thread and Bluetooth Mesh work through a hub or gateway.	ZigbeeThe Zigbee version is not stated [2]
Hub required — what it means Whether the device needs a separate hub, gateway or coordinator to work in a smart home. If so, it is sold separately unless stated otherwise.	RequiredPage FAQ: a hub is required and the maker recommends a Tuya Zigbee hub. The manual requires a Zigbee hub in the app before the light is added. The hub is sold separately [3]
Matter support — what it means Whether the device supports the Matter standard, directly or through a bridge. Matter lets you add it to Apple Home, Google Home, Alexa and Home Assistant.	Not stated by the manufacturer
Home Assistant — what it means How the device connects to Home Assistant: a built-in integration, a Zigbee coordinator, Matter or the maker’s cloud integration.	Not stated by the manufacturer
App — what it means The maker’s app used to set up and control the device.	MOES, Tuya Smart / Smart LifeThe manual describes setup in Smart Life; the page names the MOES / Tuya / Smart Life apps [3]
Compatible hubs	Tuya Zigbee hub recommended; the maker also claims it works with Philips Hue and Samsung SmartThingsThis is the maker's claim; specific Philips Hue and SmartThings hub models are not named [3]

Model and version1

Colour — what it means The housing colour of this model. Other colours in the same series are separate products.	White [3]

Control and features1

Power-on state after outage	Keeps its previous settings after being switched off at the wall [3]

Operating conditions2

Storage temperature	−40…100 °C [2]
Storage humidity	up to 85%Relative humidity, storage before the package is opened [2]

Package contents1

Manufacturer warranty — what it means The warranty period the maker states. Confirm warranty terms in Moldova with the seller.	24 monthsPer the SERVICE section of the manual: two years from the date of receipt [2]
