Moes · ZK-SR-EU-GY-MS

Moes Star Ring ZK-SR-EU Zigbee in-wall Schuko socket 16 A with energy meter, grey

Name: Moes Star Ring ZK-SR-EU Zigbee in-wall Schuko socket 16 A with energy meter, grey
Brand: Moes
SKU: ZK-SR-EU-GY-MS
Price: 549 MDL
Availability: InStock

549 MDLIn stock

In-wall sockets

Zigbee

Manufacturer image shared by the series. Check the colour, dimensions and variant in the model name and specifications.

549 MDLIn stock

What it needs to work

A compatible hub is required.

Suitable gateways and hubs

Buy with installation

Check compatibility

Connectivity: Zigbee
Maximum load current: 16 A
Energy metering: Yes

Grey in-wall Zigbee socket that measures in real time what the boiler, AC or fridge draws and cuts standby on a schedule.

36 specifications from manufacturer documents

We deliver across Moldova. Availability, delivery timing and cost are confirmed with a manager before order fulfilment.

The right choice starts with specifications

Device passport

SKU: ZK-SR-EU-GY-MS · Document model: ZK-SR-EU

Specifications checked against the linked manufacturer documents. Load limits, package details and measurement conditions are retained.Checked 18 October 2026

Connectivity and compatibility11

Connectivity — what it means The wireless link or network the device uses. Wi-Fi connects straight to the router; Zigbee, Thread and Bluetooth Mesh work through a hub or gateway.	ZigbeeZigbee 3.0 (IEEE 802.15.4, 2.4 GHz). The socket acts as a Zigbee router and extends the mesh, but it is not a hub itself [1]
Hub required — what it means Whether the device needs a separate hub, gateway or coordinator to work in a smart home. If so, it is sold separately unless stated otherwise.	Hub requiredA MOES / Tuya Zigbee gateway is needed (sold separately); without it only the button on the housing works [1]
Matter support — what it means Whether the device supports the Matter standard, directly or through a bridge. Matter lets you add it to Apple Home, Google Home, Alexa and Home Assistant.	NoThe maker does not claim Matter; the device uses Zigbee [1]
Home Assistant — what it means How the device connects to Home Assistant: a built-in integration, a Zigbee coordinator, Matter or the maker’s cloud integration.	Via a hub or coordinatorMOES states Zigbee2MQTT compatibility; according to the maker, ZHA is not supported [1]
Works without internet — what it means Whether the device keeps working over the local network or through a hub when the internet is down. Cloud features (remote access, voice assistants) need the internet.	YesThrough Zigbee2MQTT with a local Zigbee coordinator (compatibility stated by MOES). The maker does not describe whether MOES / Tuya gateway automations run without internet [1]
App — what it means The maker’s app used to set up and control the device.	MOES (Tuya Smart / Smart Life also work)The manual recommends the MOES app; Tuya Smart / Smart Life also work. Voice control via Amazon Alexa and Google Assistant [2]
Zigbee version	Zigbee 3.0 [4]
Zigbee router (repeater)	Yes [1]
Radio frequencies and transmit power	2.400–2.483 GHz, channels 11–26The manual gives 2.405–2.480 GHz [1]
Transmit power — what it means The coordinator's maximum radio output. Higher power gives a steadier link to distant devices, but range in a home depends more on walls and the number of routers in the network.	10 dBmUp to +10 dBm; on-board PCB antenna, 2 dBi gain [1]
Data rate	250 kbit/s [1]

Control and features8

Socket type — what it means The socket standard. Type F (Schuko) is standard in Moldova: it takes F, C and hybrid E/F plugs; a Type F plug without a hole will not fit a Type E socket with an earth pin.	Type F (Schuko, side earth clips)Schuko socket with side earth clips, as shown in the manual drawing; the product page says 'Schuko-style EU box' [2]
Energy metering — what it means Whether the switch shows in the app how much the connected appliance uses: live power and accumulated kWh.	Yes [1]
Measured values — what it means Which quantities are measured and shown in the maker's app. “Energy exported to the grid” means counting production, e.g. from a balcony solar kit. Via a third-party hub some of this data may be missing.	Voltage, Current, Power, energy (kWh) [3]
Overload protection — what it means What happens when current, voltage or power exceed the set threshold: the device cuts the load or only sends a notification. It does not replace the circuit breaker in the panel.	Cuts off the loadOn abnormal current or voltage the socket cuts the load itself (the infographic 'Overcurrent Protection' shows cut-off at 16 A). It does not replace the panel breaker [4]
Child protection — what it means Safety shutters cover the socket contacts against inserted objects; button lock stops the socket being switched on or off with its own button.	Safety shuttersThe official infographic shows safety shutters. The page also lists 'Child Lock' without details; a button lock is not described [5]
State after power restore — what it means What state the load returns to when power comes back after an outage: on, off, as it was before, or the opposite. The options you can choose in settings are listed.	On, Off, last stateRelay status setting in the app: power on, power off, power-off memory [2]
Indicator	Single white LED; indicator mode selectable in the app [4]
Timers	Schedule, countdown, cycle and random timers [4]

Power and load6

Maximum load current — what it means The highest current the socket continuously passes to the appliance (resistive load). 16 A at 230 V is about 3.7 kW; appliances with a high inrush current leave less real headroom.	16 AFor a purely resistive load [1]
Maximum load power — what it means The highest appliance power the manufacturer allows (resistive load). Compare it with the rating plate of your boiler, heater or oven.	3500 WMaximum load power stated by the maker; rated voltage 220 V [1]
Supply voltage — what it means The supply voltage (and current, if stated) as the maker gives it. It must match your mains or adapter.	95–245 V AC, 50/60 HzRated voltage 220 V [1]
Standby power — what it means How much power the device draws on its own while idle. It matters for devices that run around the clock.	0.3 WUnder 0.3 W in standby; under 0.5 W in operation (relay on) [4]
Power source — what it means Where the device gets its power: 230 V mains, an adapter, USB, batteries or a built-in battery.	230 V mains [4]
Operating power consumption	0.5 WUnder 0.5 W [4]

Model and version2

Colour — what it means The housing colour of this model. Other colours in the same series are separate products.	GreyMaker's variant 'Grey'. Photos show a dark grey shade [1]
Device model	ZK-SR-EU [4]

Housing and installation6

Wall box type — what it means Which wall box the mechanism is designed for. Moldova and the EU mostly use round Ø60 mm boxes; square 86 × 86 mm boxes are less common.	Not stated by the manufacturer
Terminal wire size — what it means Cross-section of copper wire the terminals accept. The line's wire must match the rating of its breaker.	Not stated by the manufacturer
Dimensions — what it means The device’s size in millimetres as the maker states it. Check that it fits the wall box, niche or shelf.	86 × 86 × 47.5 mmTotal depth 47.5 mm, of which 32.5 mm goes into the wall box (per the manual drawing) [2]
Certifications — what it means Standards and certifications the maker lists for this model (for example CE, RoHS, Zigbee 3.0, Matter).	CE, RoHSEU declaration of conformity for type ZK-SR-EU: Directives 2014/53/EU (RED), 2014/35/EU, 2014/30/EU, 2011/65/EU (RoHS) [2]
Neutral wire (N) — what it means Whether the wall box needs a neutral wire. Older wiring often brings only the live wire to the switch; then pick a model that works without N.	RequiredLive, neutral and earth are needed [2]
Mounting — what it means How and where it is installed: in a wall box, on a wall or ceiling, on a DIN rail, on a table or in a socket.	In a wall box behind the switch [2]

Operating conditions3

Operating temperature — what it means The air temperature range the device is rated for. The lower limit matters outdoors, on balconies and in unheated rooms.	−10…45 °C [4]
Operating humidity — what it means The rated relative humidity range, non-condensing.	up to 90%Non-condensing [4]
Storage temperature	−15…65 °C [4]

Package contents2

Manufacturer warranty — what it means The warranty period the maker states. Confirm warranty terms in Moldova with the seller.	24 monthsPer the warranty terms in the manual, from the purchase date [2]
Package contents — what it means What comes in the box, per the maker.	Socket ×1, screws ×2, manual ×1 [2]
