Sonoff · SNZB-01M

Sonoff Orb 4-In-1 SNZB-01M Zigbee / eWeLink-Remote scene button, 4 keys

Name: Sonoff Orb 4-In-1 SNZB-01M Zigbee / eWeLink-Remote scene button, 4 keys
Brand: Sonoff
SKU: SONOFF-SNZB-01M
Price: 549 MDL
Availability: InStock

549 MDLIn stock

Scene buttons & remotes

Zigbee

Manufacturer images

549 MDLIn stock

What it needs to work

The requirement depends on the connection method.

Suitable gateways and hubs

Buy with installation

Check compatibility

Connectivity: Zigbee, eWeLink-Remote (Sonoff)
Number of keys: 4
Power source: Batteries

Movie night starts before the phone is found — one press on the Orb 4-In-1 fires the whole scene. Four buttons, up to 16 commands in Zigbee mode (12 in eWeLink-Remote); pair it with a Zigbee or eWeLink-Remote gateway.

Hubs and systems: compatibility and limitations 11

SONOFF ZBBridge-PSupported
Connection: Zigbee / eWeLink
The manufacturer lists this hub / connection method. Features depend on the integration and firmware; see the manufacturer matrix.
Supported functions: Scene trigger · History record · Local scene · OTA
SONOFF ZBBridge-USupported
Connection: Zigbee / eWeLink
The manufacturer lists this hub / connection method. Features depend on the integration and firmware; see the manufacturer matrix.
Supported functions: Scene trigger · History record · Local scene · OTA
SONOFF NSPanel ProSupported
Connection: Zigbee / eWeLink
The manufacturer lists this hub / connection method. Features depend on the integration and firmware; see the manufacturer matrix.
Supported functions: Scene trigger · History record · Local scene · OTA
SONOFF iHostSupported
Connection: Zigbee / eWeLink
The manufacturer lists this hub / connection method. Features depend on the integration and firmware; see the manufacturer matrix.
Supported functions: Scene trigger · History record · Local scene · OTA
Home Assistant (ZHA)Supported
Connection: ZHA
The manufacturer lists this hub / connection method. Features depend on the integration and firmware; see the manufacturer matrix.
Supported functions: Scene trigger · History record · Local scene · OTA
Home Assistant (Zigbee2MQTT)Supported
Connection: Zigbee2MQTT
The manufacturer lists this hub / connection method. Features depend on the integration and firmware; see the manufacturer matrix.
Supported functions: Scene trigger · History record · Local scene · OTA
Samsung SmartThings Hub V3Supported
Connection: Zigbee / SmartThings
The manufacturer lists this hub / connection method. Features depend on the integration and firmware; see the manufacturer matrix.
Supported functions: Scene trigger · History record · Local scene
Aeotec Smart Home Hub V3Supported
Connection: Zigbee / SmartThings
The manufacturer lists this hub / connection method. Features depend on the integration and firmware; see the manufacturer matrix.
Supported functions: Scene trigger · History record · Local scene
Philips HueNot supported
Connection: Zigbee
This manufacturer manual explicitly states no support.
IKEA gatewayNot supported
Connection: Zigbee
This manufacturer manual explicitly states no support.
FRITZ!Box Zigbee gatewayNot supported
Connection: Zigbee
This manufacturer manual explicitly states no support.

29 specifications from manufacturer documents

We deliver across Moldova. Availability, delivery timing and cost are confirmed with a manager before order fulfilment.

The right choice starts with specifications

Device passport

SKU: SONOFF-SNZB-01M · Document model: SNZB-01M

Specifications checked against the linked manufacturer documents.Checked 18 October 2026

Connectivity and compatibility10

Connectivity — what it means The wireless link or network the device uses. Wi-Fi connects straight to the router; Zigbee, Thread and Bluetooth Mesh work through a hub or gateway.	Zigbee, eWeLink-Remote (Sonoff)Two modes, chosen with a slide switch under the battery cover (Zigbee by default). Zigbee IEEE 802.15.4; in eWeLink-Remote mode the button works with SONOFF devices that have the eWeLink-Remote gateway function [1]
Hub required — what it means Whether the device needs a separate hub, gateway or coordinator to work in a smart home. If so, it is sold separately unless stated otherwise.	Hub optionalScenes need a Zigbee gateway (SONOFF ZBBridge-P, ZBBridge-U, NSPanel Pro, iHost, Samsung SmartThings Hub V3 / Aeotec V3, or a Zigbee adapter with Home Assistant) or a SONOFF device with the eWeLink-Remote gateway function (MINIR4, MINI-RBS, MINI-D relays, M5 switch, etc.). Without a gateway the button controls compatible bulbs directly via TouchLink [1]
Direct control without a hub — what it means Whether the button can control compatible bulbs, relays or controllers directly, with no gateway or internet — via TouchLink, direct Zigbee binding or radio pairing with a receiver. Which devices this works with is in the note.	YesVia TouchLink with TouchLink-capable Zigbee bulbs (Philips Hue and IKEA verified), up to 10 bulbs: key 1 on/off, hold keys 2 and 3 to brighten/dim, key 4 switches scenes. Also supports direct Zigbee binding, set up via ZHA or Zigbee2MQTT, and eWeLink-Remote receivers [4]
Wireless range — what it means The stated radio range, usually in open space. Walls and floors cut it noticeably.	130 mIn open space, per SONOFF; the operating mode is not specified [1]
App — what it means The maker’s app used to set up and control the device.	eWeLinkThrough a SONOFF gateway. Also works with SmartThings and Home Assistant; in Apple Home via a software Matter bridge (eWeLink CUBE) [1]
Home Assistant — what it means How the device connects to Home Assistant: a built-in integration, a Zigbee coordinator, Matter or the maker’s cloud integration.	Via a Zigbee coordinator or hubVia a Zigbee adapter (e.g. ZBDongle-P/-E) in ZHA or Zigbee2MQTT; ZHA needs SONOFF's script. Direct binding is supported [1]
Processor / radio chip — what it means The microcontroller or radio module inside, per the maker (for example ESP32). For firmware such as WLED and ESPHome it determines available features and whether the device can be re-flashed.	TLSR8656F512ET32 [1]
Radio frequencies and transmit power	Zigbee 2405–2480 MHz, BLE 2402–2480 MHz; output ≤ 10 dBm [3]
Compatible gateways	Zigbee: SONOFF ZBBridge-P, ZBBridge-U, NSPanel Pro, iHost, ZBDongle-P, ZBDongle-E, Dongle-M, Dongle-PMG24, Dongle-LMG21; Samsung SmartThings Hub V3 / Aeotec V3. eWeLink-Remote: M5, MINIR4, MINI-RBS, MINI-D, etc.Philips Hue, Amazon Alexa, IKEA and FRITZ!Box gateways are not supported [3]
Apple Home	Via a software Matter bridge (eWeLink CUBE) or ZBBridge-U [2]

Control and features5

Device form — what it means What the device looks like and where it is used: a wall panel in place of a regular switch, a compact button you can stick anywhere or carry around, a handheld remote, or a desktop rotary knob.	Compact buttonA round Ø50 mm button on a square magnetic base; it can be lifted off and carried as a remote [2]
Number of keys — what it means How many separate buttons or touch keys can each be given their own commands. For lighting remotes with zone keys, the number of zones is given separately.	4 [1]
Press types — what it means Which actions the button tells apart: single, double or triple press, long press, turning. Each can trigger its own scene, so one button does the job of several. If the set depends on the gateway or mode, this is stated in the note.	Single press, double press, triple press, long pressTriple press works in Zigbee mode only; eWeLink-Remote mode has single, double and long press. Presses of a double or triple press must be under 0.5 s apart [3]
Number of commands (scenes) — what it means How many different commands the device can be given in total — keys × press types — according to the manufacturer. The actual number may depend on the gateway or app; this is stated in the note.	164 keys × 4 press types in Zigbee mode. In eWeLink-Remote mode — 12 (no triple press); with SmartThings Hub V3 — 12 [1]
Control type — what it means How you operate the device by hand: a mechanical button with travel and a click, touching glass with no travel, a rotary knob, or a touch ring for picking colour and brightness.	Mechanical keysFour press keys arranged as quarters of the round face [3]

Power3

Power source — what it means Where the device gets its power: 230 V mains, an adapter, USB, batteries or a built-in battery.	Batteries [1]
Batteries or battery — what it means Which cells it takes and how many. A built-in rechargeable battery is stated in the value.	1 × CR2477 [1]
Battery life — what it means Typical life on one set of batteries or one charge, per the maker. Frequent triggers, cold and a weak signal shorten it.	48 monthsAt least 4 years in Zigbee mode and 2 years in eWeLink-Remote mode — SONOFF lab data at room temperature and 50 presses a day [1]

Lighting2

Light adjustment from the device — what it means What you can change about the light right from the device besides on/off: brightness, colour temperature, colour, dynamic modes. Works only with compatible lights and controllers.	BrightnessBrightness for bulbs paired via TouchLink (hold keys 2 and 3) or Zigbee binding (a long press toggles the dimming direction). Colour and colour-temperature changes are not stated [4]
Bulbs via TouchLink	10A bulb stays paired with one remote only: pairing it to a second remote disconnects the first [4]

Housing and installation6

Mounting — what it means How and where it is installed: in a wall box, on a wall or ceiling, on a DIN rail, on a table or in a socket.	Magnetic, adhesive tape, screw-fixed (surface)The base sticks on with VHB tape or is screwed to a wall box; the button holds to the base magnetically. Mounting height up to 2 m [3]
Dimensions — what it means The device’s size in millimetres as the maker states it. Check that it fits the wall box, niche or shelf.	Ø50 × 22.5 mmButton size; the square base size is not stated [1]
Weight — what it means The device’s weight without packaging, per the maker.	53 gIncluding the battery [1]
Housing material	Polycarbonate (PC) [1]
Certifications — what it means Standards and certifications the maker lists for this model (for example CE, RoHS, Zigbee 3.0, Matter).	CE, FCC, RoHS [1]
Maximum mounting height	2 m [3]

Model and version1

Colour — what it means The housing colour of this model. Other colours in the same series are separate products.	White [1]

Operating conditions2

Operating temperature — what it means The air temperature range the device is rated for. The lower limit matters outdoors, on balconies and in unheated rooms.	−10…60 °C [1]
Operating humidity — what it means The rated relative humidity range, non-condensing.	5–95%Non-condensing; indoor use only [1]
