IMOU · N110W

IMOU N110W Wi-Fi 6 NVR, 10 channels, local HDD recording up to 16 TB

Name: IMOU N110W Wi-Fi 6 NVR, 10 channels, local HDD recording up to 16 TB
Brand: IMOU
SKU: NVR-N110W-8A0E
Price: 2499 MDL
Availability: InStock

2,499 MDLIn stock

NVR recorders

Wi-Fi

Ethernet

Manufacturer images

2,499 MDLIn stock

Buy with installation

Check compatibility

Channels (cameras): 10
PoE ports for cameras: 0
Max capacity per drive, TB: 16

The Wi-Fi 6 version of the N110 recorder: up to 10 cameras over its own Wi-Fi (up to 8 on 2.4 GHz, up to 10 on 5 GHz) or by cable, recording to an HDD up to 16 TB (sold separately). Battery cameras are not supported.

30 specifications from manufacturer documents

We deliver across Moldova. Availability, delivery timing and cost are confirmed with a manager before order fulfilment.

The right choice starts with specifications

Device passport

SKU: NVR-N110W-8A0E

Specifications checked against the linked manufacturer documents.Checked 18 October 2026

Control and features2

Channels (cameras) — what it means How many cameras the recorder can record at the same time. Wireless recorders may have a separate limit for cameras connected over Wi-Fi — it is given in the note.	10Over Wi-Fi: up to 8 cameras on 2.4 GHz and up to 10 on 5 GHz; wired via a router or switch: up to 10. No more than 10 channels in total [1]
IMOU camera auto-pairing	Yes: new IMOU cameras connect to the recorder automaticallyA short press of the Reset button enables auto-pairing of new IMOU Wi-Fi cameras for about 2 minutes [1]

Power3

PoE ports for cameras — what it means How many cameras can plug straight into the recorder with one cable carrying both video and power. With no PoE ports (0), cameras connect through the router or a separate PoE switch and run on their own adapters.	0No PoE ports: one RJ-45 network port and its own Wi-Fi network for cameras [1]
Supply voltage — what it means The supply voltage (and current, if stated) as the maker gives it. It must match your mains or adapter.	12 V ⎓ 2 A (external adapter included) [1]
Rated power — what it means The rated or maximum power draw from the spec sheet. It sets the load on the socket and the energy use.	19 WPeak draw with a drive is under 19 W; average with a drive is under 9 W [1]

Connectivity and compatibility10

Connectivity — what it means The wireless link or network the device uses. Wi-Fi connects straight to the router; Zigbee, Thread and Bluetooth Mesh work through a hub or gateway.	Ethernet (cable), Wi-FiWi-Fi 6 (IEEE 802.11b/g/n/ax), 4 external antennas; Ethernet 1 × RJ-45, 10/100 Mbps [1]
Incoming bandwidth — what it means The total video stream from all cameras the recorder can take in. Together with the channel count it decides how many high-resolution cameras can be recorded at once; each camera's bitrate is in its own specifications.	90 Mbps90 Mbps incoming and 90 Mbps outgoing; the same for Wi-Fi and wired [1]
Other brands' cameras (ONVIF / RTSP) — what it means ONVIF is an open standard: a recorder that supports it records other brands' cameras if they support ONVIF too. The profile (S, T) and limits are in the note; some features, such as event detection, may work only with the same brand's cameras.	ONVIFONVIF Profile T. Wired connection is recommended for other brands' cameras. Separate support for cameras by RTSP link is not described [3]
Compatible cameras — what it means Which cameras the recorder accepts per the manufacturer's documentation: its own wired and wireless ones, other brands via ONVIF, and which are not supported, such as battery cameras.	Mains-powered wired and Wi-Fi IMOU cameras (auto-pairing) and other brands' ONVIF cameras. Battery cameras, including IMOU ones, are not supported. [2]
Wi-Fi band — what it means 2.4 GHz passes through walls better and reaches further, but is more often crowded by neighbours' networks. 5 GHz is faster and less congested but weaker behind walls. A 2.4 GHz-only camera won't join a network that runs on 5 GHz only. The Wi-Fi generation (e.g. Wi-Fi 6) is in the note.	2.4 GHz, 5 GHzUp to 8 cameras on 2.4 GHz and up to 10 on 5 GHz. The manual warns that more 5 MP cameras on one band may cause video delays [1]
Monitor outputs — what it means Connectors for a monitor or TV and the highest resolution on each. They let you watch the archive on site without a phone.	1 × HDMI up to 4K (3840 × 2160); 1 × VGA up to 1080pHDMI: 3840 × 2160, 2560 × 1440, 1920 × 1080, 1600 × 1200, 1280 × 1024, 1280 × 720. VGA: 1920 × 1080, 1280 × 1024, 1280 × 720 [1]
USB ports — what it means How many and which USB ports are available for extra devices: Z-Wave or Zigbee coordinators, drives, modems.	2 × USB (front and rear; the rear one is USB 2.0)For a mouse and a USB stick (backup of recordings as MP4) [4]
App — what it means The maker’s app used to set up and control the device.	Imou Life (iOS, Android)The recorder can also be operated from a monitor with a mouse [1]
Number of antennas — what it means How many antennas the device has; whether they are external or built-in and how they are split between bands is in the note. The antenna count alone is not the same as coverage, which also depends on transmitter power, walls and placement.	4External [1]
Ethernet port	1 × RJ-45, 10/100 Mbps [1]

Imaging and recording7

Max capacity per drive, TB — what it means The largest drive, in terabytes, each bay accepts. How many days of archive fit depends on the number of cameras, their resolution, codec and recording mode — continuous or on events.	16 [1]
Hard drive bays — what it means How many SATA hard drives can be fitted. The total archive size is the combined capacity of all drives fitted; the drive format (3.5″ or 2.5″) is in the note.	1One bay for a 3.5″ SATA hard drive [1]
Max camera resolution — what it means The highest camera resolution the recorder accepts and records. Limits for particular modes or for how many such cameras can be used are in the note.	8 MPThe maker states decoding of 4 channels at 8 MP and 15 fps; no separate recording resolution limit is given. For Wi-Fi connection the manual gives limits for 5 MP cameras [1]
Simultaneous playback — what it means How many channels, and at what resolution, the recorder can play back at once, e.g. “4 × 8 MP at 15 fps”. It decides how many cameras you can watch on one screen without losing quality.	Up to 4 channels at once: 4 × 8 MP at 15 fps or 4 × 5 MP at 30 fpsSpeeds 2×, 4×, 8×, 16×. Overall decoding capability per the datasheet: 4 × 8 MP at 15 fps; 4 × 6 MP at 25 fps; 4 × 5 MP at 30 fps; 5 × 4 MP at 30 fps; 10 × 1080p at 30 fps [3]
Video codec	H.265 / H.264; audio AAC [1]
Audio and two-way communication	Built-in microphone and speaker, two-way audio [1]
Live view layouts	1, 4, 8, 9, 10 tiles [1]

Package contents2

Hard drive included — what it means Whether a drive is in the box. If not, it is bought separately: without a drive the recorder keeps no recordings.	NoThe official IMOU store states the drive is not included or preinstalled [2]
Package contents	Recorder, power adapter, mouse, SATA power cable, SATA data cable, Ethernet cable, screw pack, quick start guide, regulatory information [1]

Measurement and detection1

Event search in recordings — what it means Which events the recorder tags in recordings so you can find a clip quickly. This often works only with the same maker's cameras, which recognise people or vehicles themselves; the conditions are in the note.	Motion, Person, VehicleSmart Search in recordings: motion, person, vehicle. Events are recognised by the camera itself (the camera must support the detection); the recorder indexes them, and person search can filter by gender, clothing and hairstyle [1]

Operating conditions2

Operating temperature — what it means The air temperature range the device is rated for. The lower limit matters outdoors, on balconies and in unheated rooms.	−10…45 °C [1]
Operating humidity	up to 95% RH [1]

Housing and installation2

Dimensions (W × H × D) — what it means The device’s size in millimetres as the maker states it. Check that it fits the wall box, niche or shelf.	241.5 × 260 × 60.2 mmWith antennas folded. The maker gives the order as L × W × H [1]
Device mass	890 gWithout a drive [1]

Model and version1

Manufacturer certifications	CE [1]
