Fix the 18,000–24,000 BTU outdoor unit on the façade or balcony, freeing up ground-level space and ensuring airflow.
What it is, who it's for, what it does
About this product
Secure your air-conditioner outdoor unit to the wall with this set of two welded L-600 consoles. The 600 mm base and roughly 450–500 mm height suit most outdoor units in the 18,000–24,000 BTU range. A welded fixed design from 2 mm steel plate carries a maximum load of up to ~100 kg per unit, with no play and no added vibration. White electrostatic powder-coat protects the steel against corrosion in outdoor conditions. The kit ships with 2 brackets, ready to install with fasteners suited to your wall (not included). The product carries 24 months of official warranty.
- DeliveryDelivery 50 MDL
- Returns14 days to return
- Warranty24 months
15+projects delivered300+devices installed3 yearslocal-first experienceChișinăushowroom Columna 153Book a showroom visit →
Where it works
Use cases
Swap worn consoles for a new 2 mm steel set with anti-corrosion coating, for a secure hold of the same outdoor unit.
Support more powerful outdoor units (up to ~100 kg) on concrete or brick walls with a firm, vibration-free fixing.
For the installerTechnical specificationsfull spec · wiring · datasheet
For the installer
Technical specifications
full spec · wiring · datasheet
Other
- Type
- Welded fixed bracket (console) for outdoor unit
- Base length (L)
- 600 mm (L-600)
- Height
- ~450–500 mm
- Max. load
- up to ~100 kg (per unit)
- Compatibility
- Outdoor units 18,000–24,000 BTU
- Kit
- 2 pcs (set of 2 brackets)
- Color
- White
Physical
- Material
- Steel, 2 mm thickness, electrostatic coating (white)
Support
Frequently asked questions
Does it need Wi-Fi or an app?
No. It is a passive steel bracket with no electronics, no connectivity and no app — its role is purely structural, holding the outdoor unit on the wall.How much weight does the set hold?
The recommended maximum load is up to ~100 kg per unit, enough for outdoor units in the 18,000–24,000 BTU range. Always check your unit's actual weight.Are anchors and bolts included?
No. The set includes 2 steel brackets. Anchors and bolts are chosen for your wall type (concrete, brick, aerated block) and are not included.Which AC sizes is it compatible with?
The bracket is sized for outdoor units in the 18,000–24,000 BTU range. The 600 mm base (L-600) fits most units in this segment.Will it rust outdoors?
The steel is finished with a white electrostatic coat that forms a hard, corrosion-protecting layer. For maximum life, avoid scratching the coating during installation.How long is the warranty?
The product comes with 24 months of official warranty.
